New Floating Docks

Principal dimensions:

Length =123,21 m, Width outside/inside =30/25 m, Depth above=6 m + 1,0 m for trimming, Lifting capacity: up to 5 000 tons

Advantages:

• ideal for shallow waters – pontoon depth only 2,5 m
• wide inside – 25 m which enables mechanization of work around the ship,
• very strong, monolith construction,
• product of Poland, all materials and equipment European make,
• Hempel’s guarantee on total painting 5 years,
• built and certified under IACS class of Polski Rejestr Statków (PRS),
• two cranes fixed type 5 and 8 Tons, remote controlled,
• special winch system for lead ship into the dock reducing number of dockmen to 4 persons,
• environmental complying with European requirements,
• electrically autonomic – class accepted 4 (or 6) units generator sets Atlascopco QAS 125
• special rotating fender on ship gate allowing for smooth lead of the vessel into the dock
• equipped with special tensometer system for control of dock hull deformation (specially important for heavy vessels),
• prepared for towing on harbour water with ship docked inside,
• operational at normal pier on mooring ropes
• Delivered as turn key product.
• Production time: 12 months
